Export

Once you have created all the toolpaths you need, you can save out the different toolpaths for your machine.

Select the appropriate post-processor for your machine. It is likely that your machine has only one post-processor, but if not, then use the one suggested by your machine manufacturer.

Select Post-processor

Check your toolpaths

You should check the toolpath preview in the view to make sure that the toolpaths are what you expect. Also, make sure you're using the correct cutting data from your tool database and that your toolpaths have been updated to use them.

Select each toolpath you wish to save by clicking on the checkbox next to the toolpath name.

Toolpath List

Then click on the 'Export' button. This will post-process the selected toolpaths and they will automatically be downloaded to your computer.

Export Toolpaths

Export Preview Image​

The Export Preview Image button in the view toolbar saves the current toolpath preview as a PNG file to your computer.

The button is disabled when the toolpath preview is not visible in the view.
